PP175A
PP connector; Compact ergonomic housing; Rated current 52A;
Provides protection against accidental contact with live circuits, critical for DC voltages above 30V; supports hot swapping up to 45A at 72V; uses flat-wiping technology.
POLO POWER CONNECTORS USED IN Lithium battery systems suitable for harsh environments such as electric vehicles, energy storage systems, industrial and commercial electric equipment, etc. Made of high-quality materials, low impedance, and excellent Conductivity.
Product Description
Polycarbonate housings feature three finger proof positions. The center position can be used for pre-mate power or ground. Genderless design mates with itself, or the PCB connector. Mechanical keys are color coded. Inquire with customer service for chemical resistant housings.
The patented SBS® connector family is designed to provide high power in a compact ergonomic housing with protection against accidental contact with live circuits.
Touch Safe Interface can safely be used in through panel applications and minimizes potential contact with live circuits per IEC 60950
Wire-to-Wire and Wire-to-Board Configurations Allows one connector to meet multiple needs
Technical Drawings
Technical Specifications
Port No. | A | B | C | D | Wire |
|---|---|---|---|---|---|
PP1382-T | 57.3 ± 0.5 | 25.7 ± 0.5 | 11.2 ± 0.5 | 13.0 ± 0.5 | 1/0AWG |
PP1383-T | 57.3 ± 0.5 | 25.7 ± 0.5 | 9.1 ± 0.5 | 13.0 ± 0.5 | 2AWG |
PP1384-T | 57.3 ± 0.5 | 25.7 ± 0.5 | 7.9 ± 0.5 | 13.0 ± 0.5 | 4AWG |
PP1386-IT | 55.8 ± 0.5 | 25.7 ± 0.5 | 5.7 ± 0.5 | 11.0 ± 0.5 | 6AWG |
